Plain Monofilament 3.9M Polyester Screen Printing Mesh

    Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers

    Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers
    • Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers
    • Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers
    • Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers
    • Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers
    • Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers
    • Buy cheap Plain Monofilament 3.9M Polyester Screen Printing Mesh from wholesalers

    Plain Monofilament 3.9M Polyester Screen Printing Mesh

    Ask Lasest Price
    Brand Name : BJPFM
    Model Number : PFM - Polyester Printing Mesh
    Certification : SGS FDA
    Price : $ 0.7 - $1.2 / Meters
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000000 Meter/Meters per Month
    Delivery Time : 7-15 work days
    • Product Details
    • Company Profile

    Plain Monofilament 3.9M Polyester Screen Printing Mesh

    Polyester Screen Printing Mesh


    1. Polyester Screen Printing Mesh Description

    Woven by monofilament Yarn/threads, polyester screen printing mesh is seen wide applications in different industrial printing, such as glass printing, graphic printing, ceramic printing, paper printing, circuited board printing, plastics, and packaging printing.


    PFM SCREEN has been dedicating herself to research, development, and production of high-quality polyester printing mesh since 1987, importing Swiss Weave Looms and German Reeds to produce mono-filament polyester printing mesh, other than equipment, we also import quality yarns to weave mesh; Our trained workers, together with advanced machines, equipment, can weave high-quality printing mesh; By improving our quality, we also are thinking of ways to reduce costs, so we can give our clients' lower price to reduce their production cost.


    Plain Monofilament 3.9M Polyester Screen Printing Mesh


    2. Polyester Screen Printing Mesh Features

    • Faster Tensioning without damage to the threads
    • Improved fabric strength
    • Faster Tension Stabilization
    • Higher tension threshold and breaking point
    • Less tension loss during the stretching process
    • Faster turnaround time from the screen room to the press room
    • Improved registration due to stable tension
    • Faster print speed

    3. Polyester Screen Printing Mesh Specification

    Mesh count diameter
    (mesh/cm/μm)
    Mesh count (mesh/inches)WeaveAperture (μm)Thread diameter (μm)Opening (%)Thickness (μm)Thickness tolerance (± μm)Theoretical ink (cm3/m2)Weight (g/m2)
    13 (T)-150PW (SL)331:1619150643001412860
    21-80PW (S)551:1296806912097935
    21-150PW (SL)551:13261504626014118121
    24-100PW (T)601:131610057136116581
    28-140PW (SL)701:1217140401951376125
    32-55PW (S)811:1257556710366728
    32-64PW (S)811:124864639565632
    32-100PW (T)811:12121004516587375
    36-90PW (T)921:1183904415086568
    39-55PW (S)1001:117755568865530
    40-80PW (T)1031:1166804413375960
    43-80PW (T)1101:1149804113075364
    47-45PW (S)1202:216645*2618064240
    47-55PW (S)1201:115255518864834
    48-70PW (T)1221:1133704111564755
    53-45PW (S)1352:214345*2577974146
    53-55PW (S)1351:113355508664240
    54-64PW (T)1371:1115643910053951
    54-70PW (HD)1371:1109703511664062
    61-64PW (T)1551:190643110153058
    64-55PW (S)160
