100% Polyester Silk Screen Printing Mesh 32T - 120T With High Air Permeability

32T 36T 39T 43T 47T 54T 59T 64T 72T 77T 80T 90T 100T 120T Polyester Silk Screen Printing Mesh

1. Polyester Silk Screen Printing Mesh Description

100% Polyester Silk Screen Printing Mesh 32T - 120T With High Air Permeability

Product name	Polyester Silk Screen Printing Mesh
Mesh count	18-420 mesh
Color	White & Yellow
Width	127cm, 136cm, 145cm, 155cm, 158cm, 165cm
Thread diameter	31-200 Micron
Mesh opening	24-475 Micron
Thickness	55-365 Micron
Material	100% polyester
Weave type	Plain weave
Printing	Polyester screen printing
Feature	High tension, low elongation and halogen-free
Usage	Printing on Ceramics, Glass, Textile, Electronics, CD, PCB, Solar cell panel, Advertising
Sample	Available

2. Polyester Silk Screen Printing Mesh Features

1. High tension and smooth surface
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear and easy cleaning
7. We can do as customer's requests and samples.

3. Polyester Silk Screen Printing Mesh Specification

Polyester Printing Mesh(Silk Screen Printing Mesh)
Model	Mesh/cm	Mesh/inch	Aperture (μm)	Thread Dia. (μm)	Open Area (%)	Thickness (μm)	Theoretical Ink (cm³/m²⁾
36-90	36	92	183	90	44	150	65
39-55	39	100	177	55	56	88	55
43-80	43	110	149	80	41	130	53
47-55	47	120	152	55	51	88	48
48-70	48	122	133	70	41	115	47
53-55	53	135	133	55	50	86	42
54-64	54	137	115	64	39	100	39
54-70	54	137	109	70	35	116	40
61-64	61	155	90	64	31	101	30
64-55	64	160	98	55	38	98	36
64-64	64	160	85	64	30	115	34
68-55	68	175	85	55	34	85	28
68-64	68	175	78	64	28	105	30
72-48	72	182	90	48	36	78	33
72-55	72	182	85	55	30	90	27
80-48	80	200	72	48	33	74	25
90-48	90	230	56	48	25	78	19
100-40	100	255	58	40	33	63	21
110-40	110	280	48	40	27	64	17
120-31	120	305	49	31	35	49	17
120-34	120	305	45	34	30	55	16
130-34	130	330	40	34	27	55	15
140-31	140	355	36	31	26	48	12
140-34	140	355	31	34	20	53	10
150-31	150	380	32	31	23	49	11
150-34	150	380	23	34	13	55	6.5
165-31	165	420	23	31	15	48	7
Note:The above theoretic data is for reference only,and thickness tollerance is±5%.

4. Polyester Silk Screen Printing Mesh Application

The meshes can apply in Ceramic printing, Glass printing, Large poster printing, Membrane switches printing, PCB printing, Packing printing, Screen printing, Textile printing, T-shirt printing, Image printing, Medical equipment printing and so on.
